tallchickbarbara
Shiny_Rock
- Joined
- Oct 31, 2003
- Messages
- 107
Date: 9/17/2009 7:37:49 PM
Author: John Pollard
I can help but it may not help.
Barbara is correct. In my GIA coursework - and I raised my hand to make Ric Taylor repeat this - it was stated that feathers MUST reach the surface.
But Todd and Rich are correct too. We have all seen diamonds where a crystal inclusion expanded to cause a feather in a stone that is completely internal - and it''s called a feather on the plot, even at GIA.
I know I sound like DiaGem here (is that a bad thing?) but I must proclaim this as one of those areas where the company line that is taught and what happens in reality are not in perfect harmony.
After careful checking of the time Garry made that post, I have deduced that he was at least on his second bottle of wine when answering, therefore he cannot be held responsible for his wildly incorrect response.Date: 9/18/2009 7:17:50 AM
Author: Lorelei
Ok now I am confused, Garry posted in this thread recently concerning the feather in question '' it is good that they are red though - green means it reaches the surface.''Date: 9/17/2009 4:01:36 PM
Author: Richard Sherwood
Although the vast majority of feathers are surface breaking, I''ve seen feathers which were entirely internal. Both are partially healed stress fractures, which in the case of an internal feather the diamond has crystallized beyond the extent of the feather.
If there''s another name for it (internal feather) I don''t know it. I plot it in red with the comment that it is an internal, non-surface breaking feather.
As far as I know, feathers are plotted in red, even if they break the surface. They are still considered an internal characteristic (shown in red) rather than a blemish (external characteristic shown in green).
If you see a green line on a graph it is usually a scratch, or has something to do with a natural or a cavity.
Barbara, intrigued/confused looks good on you.
https://www.pricescope.com/community/threads/question-about-si2-feather.125162/
So just to clarify, if a feather does reach the surface it won''t be plotted in green in any way? I just want to know so I am offering the best advice.
ROFL!!! Thanks for the info Rich!Date: 9/18/2009 1:30:19 PM
Author: Richard Sherwood
After careful checking of the time Garry made that post, I have deduced that he was at least on his second bottle of wine when answering, therefore he cannot be held responsible for his wildly incorrect response.Date: 9/18/2009 7:17:50 AM
Author: Lorelei
Ok now I am confused, Garry posted in this thread recently concerning the feather in question '' it is good that they are red though - green means it reaches the surface.''Date: 9/17/2009 4:01:36 PM
Author: Richard Sherwood
Although the vast majority of feathers are surface breaking, I''ve seen feathers which were entirely internal. Both are partially healed stress fractures, which in the case of an internal feather the diamond has crystallized beyond the extent of the feather.
If there''s another name for it (internal feather) I don''t know it. I plot it in red with the comment that it is an internal, non-surface breaking feather.
As far as I know, feathers are plotted in red, even if they break the surface. They are still considered an internal characteristic (shown in red) rather than a blemish (external characteristic shown in green).
If you see a green line on a graph it is usually a scratch, or has something to do with a natural or a cavity.
Barbara, intrigued/confused looks good on you.
https://www.pricescope.com/community/threads/question-about-si2-feather.125162/
So just to clarify, if a feather does reach the surface it won''t be plotted in green in any way? I just want to know so I am offering the best advice.
Heh heh heh... I say that while prostated in humility of course.
As it is considered an internal characteristic, a feather is plotted in red. I''ve never seen one plotted in green, or red and green.
Date: 9/18/2009 1:09:06 PM
Author: Todd Gray
Apparently Wink from High Performance Diamonds and I both sent Peter Yantzer, Director of the AGS Laboratory an email referencing this thread and requesting clarification and this is what we received from Peter:
Fractures and cleavages are cracks in the stone.
They are euphemistically called feathers so as to not alarm consumers.
Peter Yantzer is also the former Lab Director for GIA Carlsbad...
And of course you were not busy all day and thus beat me to the punch in quoting Peter, although you need to not do this in Word as you can see that it makes a mess of the paste!Date: 9/18/2009 1:09:06 PM
Author: Todd Gray
Apparently Wink from High Performance Diamonds and I both sent Peter Yantzer, Director of the AGS Laboratory an email referencing this thread and requesting clarification and this is what we received from Peter:
Fractures and cleavages are cracks in the stone. They are euphemistically called ‘feathers’ so as to not alarm consumers. The vast majority of feathers break the surface of the stone but you can have an internal feather. A really good example is a classic inclusion that has a small crystal in the center and then a feather that radiates outward from the crystal for a full 360 degrees. I think they are probably caused by a difference of expansion between the included crystal and the host diamond. You may have referred to them or heard them being called ‘lily pad’ inclusions. As far as plotting them, if the ‘lily pad’ inclusion is parallel to the table you might see a circle on our plots. If the ‘lily pad’ inclusion is perpendicular to the table you would probably see a small circle and a feather line, both plotted in red, extending on both sides of the crystal.
All of the posts on the linked thread below help to point out that it’s a good idea to have an expert in your area to consult with if you have a question about your diamond.
Peter Yantzer is also the former Lab Director for GIA Carlsbad...
Oh, no John, I caught it and actually referenced what you said in a follow up post to Wink: "I believe John''s response also suggests that this is indeed something taught by the GIA to graders/Gemologists."Date: 9/18/2009 7:27:48 PM
Author: John Pollard
Hey Barbara,
You may have missed the post where I supported you; what you''re quoting is indeed what''s taught... But in this case I have found policy is different than practice. I have the same lab manual with the same graphic btw. And my instructor was Ric Taylor, whom I consider among the best in the biz. Nevertheless, in reality ''it is what it is.''
Haha. Like winning the lottery - but finding out you're sharing the pot, eh?Date: 9/18/2009 7:58:46 PM
Author: BarbaraP
Oh, no John, I caught it and actually referenced what you said in a follow up post to Wink: 'I believe John's response also suggests that this is indeed something taught by the GIA to graders/Gemologists.'
I was starting to feel a bit batty about it so it was nice to have my statement called 'correct', even if I had to share in that correctness.
he he heDate: 9/18/2009 1:30:19 PM
Author: Richard Sherwood
After careful checking of the time Garry made that post, I have deduced that he was at least on his second bottle of wine when answering, therefore he cannot be held responsible for his wildly incorrect response.Date: 9/18/2009 7:17:50 AM
Author: Lorelei
Ok now I am confused, Garry posted in this thread recently concerning the feather in question '' it is good that they are red though - green means it reaches the surface.''Date: 9/17/2009 4:01:36 PM
Author: Richard Sherwood
Although the vast majority of feathers are surface breaking, I''ve seen feathers which were entirely internal. Both are partially healed stress fractures, which in the case of an internal feather the diamond has crystallized beyond the extent of the feather.
If there''s another name for it (internal feather) I don''t know it. I plot it in red with the comment that it is an internal, non-surface breaking feather.
As far as I know, feathers are plotted in red, even if they break the surface. They are still considered an internal characteristic (shown in red) rather than a blemish (external characteristic shown in green).
If you see a green line on a graph it is usually a scratch, or has something to do with a natural or a cavity.
Barbara, intrigued/confused looks good on you.
https://www.pricescope.com/community/threads/question-about-si2-feather.125162/
So just to clarify, if a feather does reach the surface it won''t be plotted in green in any way? I just want to know so I am offering the best advice.
Heh heh heh... I say that while prostated in humility of course.
As it is considered an internal characteristic, a feather is plotted in red. I''ve never seen one plotted in green, or red and green.
As usual Dave you do a great job of elegant simplifcation.Date: 9/19/2009 2:49:54 AM
Author: oldminer
An inclusion which breaks the surface continuity of a diamond is of greater concern for durability than one of the same relative location and size which is totally internal. It is quite apparent from the diverse and vast expertise in this thread that the use of pleasing or less pleasing words to decribe inclusions is spotty (pardon the pun) at best.
The best way to describe inclusions is to draw them on plots with green indicating surface reaching blemishes and red showing their intneral size and location. Using red combined with green does the job quite well. Naming such inclusions is nice, but we surely don''t have a unified definition which the entire industry can currently agree upon. We think we have adequate definitions in place most of the time, but when one digs below the surface we begin to see problems that we really are well aware of. We must contine to function even with such limitations.
I prefer open blemishes on the pavilion to ones on the crown or to any which are in the girdle. I think durability issues over-ride whatever we call them. I call inclusions ''feather'' when the ''look something like'' feathers. Otherwise I just describe with visuals and call inclusions as ''open'' ''closed''
''crystal'' etc. I may think ''gletz'', but I rarely use this dealer to dealer term with any one but a diamond dealer.
Then what do you call a fracture that doesn''t follow the grain?Date: 9/19/2009 1:05:33 AM
Author: Garry H (Cut Nut)
Oh, I missed the main bit - in my book a feather is a feathery crack (following an octahedral growth plane or twin plane and not anything to do with healing which is entirely related to coloured gemstones where there can be chemical reactions internal to the gemstone - this is not an event that can occur in chemically stable and non reactive carbon)
And it matters not if it is inside only or surface meeting.
I guess it is possible to have a feather from other causes Marty. Not sure though. A question for Dr. Yuri I think?Date: 9/19/2009 10:17:24 AM
Author: adamasgem
Then what do you call a fracture that doesn''t follow the grain?Date: 9/19/2009 1:05:33 AM
Author: Garry H (Cut Nut)
Oh, I missed the main bit - in my book a feather is a feathery crack (following an octahedral growth plane or twin plane and not anything to do with healing which is entirely related to coloured gemstones where there can be chemical reactions internal to the gemstone - this is not an event that can occur in chemically stable and non reactive carbon)
And it matters not if it is inside only or surface meeting.
30 years - I find your explanation is far to brief to be useful.Date: 9/19/2009 10:50:16 PM
Author: 30yearsofdiamonds
Feathers at GIA will be plotted as follows;
1. If it is a feather it will always be plotted in red, never in green. In fact on the final GIA report the only green that is plotted is a natural. Everything else is either red or red with green.
2. If it is an open feather, there are options depending on the size of the opening. If it ia barely a smile, it will be plotted as a feather. If it is wide smile,(teeth showing) it will be plotted as a cavity and that is with green on the outside and red slash matks in the middle.
3. A fetaher is not based on a line or white line at the surface. It is based on depth of that surface line which is always visible from the opposite side at 10x.
Hope this is helpful.
Feathers, for the most part do not have an opening that can be perceived through a normal microscope.
When a feather has an opening that can be perceived by the grader it is usually plotted as a cavity.
Feathers cannot be felt with a probe, unless there is a slight opening.
Internal feathers are usually associated with a crystal and will be plotted on a diagram as one crystal the size of the whole inclusion.
Internal feathers may also be associated with what the GIA calls Twinning, which will be plotted as twinning.
Feathers may sometimes have fluid inside that penetrated during the cutting and boiling process. These feathers may have an iridescence not to be confused with artificially filled feathers.
Feathers often will be downgraded due to the depth and size of the feather even if its visibility is difficult to observe. At GIA they call these transparent feathers or ghost feathers, internally.
Feathers can occur naturally or through impact.
If feather is the first key to symbol listed on the report along with other characteristics, that means that the feather is the grade setter. If an internal characteristic,(crystal) is listed before a feather and both are grade setting, it is done this way because the internal grade setter has less of a chance of removal from re-cutting.
Date: 9/20/2009 12:59:13 PM
Author: 30yearsofdiamonds
Feathers can occur naturally or through impact.
Date: 9/21/2009 12:02:09 PM
Author: Richard Sherwood
I''d talk more but I''m on my way to Atlanta to see Barbara''s ''perplexed/bewildered'' look.
