Bling! pictures, understanding focus.

Discussion in 'Hangout' started by strmrdr, Jan 8, 2008.

Thread Status:
Not open for further replies.
  1. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    This mini-tutorial will just cover P&S cameras and not DSLRs as they use a totally different focus system.

    The first thing you need too know is that it is contrast based, areas where there is a large difference between light and dark is where it will focus.
    I will not get into how it does this because it is very complicated.

    This picture shows it in great detail.
    Where is the strongest contrast and where did the camera focus?


  2. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    This one is a little harder it actually focused on the shadows on the leaves.


  3. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    How can you fool it into focusing where you want?
    Provide contrast where you want it too focus...


  4. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    the results, with the paper removed before finishing pressing the shutter button...(more on that leter)
    In this lighting the camera would not focus at all with just the stone and no P&S likely would.
    A dslr might or might get a focus lock on it.


  5. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    How do you use a focus aid?

    First you pick something with high contrast that isn''t too shiny, the paper I used was actually a little too shiny but it worked OK.

    Hold it where you want the camera to focus then press the shutter button 1/2 way down.
    Then not moving the camera remove the paper and press the shutter the rest of the way.

    Method 2:
    set the aid beside the item and focus on the aid by half pressing the shutter then keeping the distance the same move the camera over to the object itself.

  6. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    too recap:
    Where did the camera focus in this shot?


  7. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    On the black white and gold area under the pendant.

  8. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    using method 2 above...


  9. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    using method 2 above but with a twist, the shadows from the pendant where the focus aid.
    By pressing the shutter 1/2 way then moving the camera back slightly.... tada


  10. D2B
    Brilliant_Rock

    Messages:
    1,067
    Joined:
    Feb 10, 2007
    by D2B » Jan 8, 2008
    thanks heaps - very useful. any other tip will be much appreciated. Great idea.[​IMG]

    Afterall, it can never be a bad idea to get more and better diamond shots[​IMG]
    [​IMG]
    D2B

  11. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    more tips:
    Before you start shooting check your manual or the web for the min. focus distance for your camera in macro mode and how too set it too macro mode.
    You do not want "super marco" also called "super close up" because the camera will block too much light that close.
    You can also try non-macro mode at a longer distance and cropping the images.
    This will often give you better fire shots than being closer.
    If you cant find out what the recomended distances are try 12 then 22 inches they are both very common.

  12. bee*
    Super_Ideal_Rock

    Messages:
    12,170
    Joined:
    May 14, 2006
    by bee* » Jan 8, 2008
    Thanks for that! I never seem to be able to take descent photos of my ring.

  13. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 8, 2008
    I would like too thank wifey2b for all her help in creating this mini-tutorial.
    I could not have done it without her :} [​IMG][​IMG]
    All errors and omissions that may be present are my fault and not hers however.

  14. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
  15. Mrs Mitchell
    Ideal_Rock

    Messages:
    2,071
    Joined:
    Sep 22, 2006
    by Mrs Mitchell » Jan 12, 2008
    Thank you (both) for taking the time to post this. Very helpful!

    Jen

  16. door knob solitaire
    Ideal_Rock

    Messages:
    2,934
    Joined:
    Jun 26, 2005
    by door knob solitaire » Jan 13, 2008
    Thanks Stormy and Wifee. You too rock, in focus no less. §

  17. partgypsy
    Ideal_Rock

    Messages:
    4,981
    Joined:
    Nov 7, 2004
    by partgypsy » Jan 14, 2008
    Thanks! That was very helpful, and makes me understand what was going on when I was previously trying to take pics (and swearing)!

  18. marvel
    Brilliant_Rock

    Messages:
    1,133
    Joined:
    Jul 8, 2005
    by marvel » Jan 22, 2008
    Thanks strmrdr and wifey! I been wanting to take better pictures of my ring, but it''s just not as easy as it looks. I''m going to give your tips a try and see how it goes.

  19. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 22, 2008
    welcome
    If your still having problems start another thread with sample pics and the specifics of your camera(make model and what not) settings used and distance to the object and I will try and help.

  20. somethingshiny
    Ideal_Rock

    Messages:
    6,746
    Joined:
    Jul 22, 2007
    by somethingshiny » Jan 22, 2008
    Strm and Wifey~ This thread is a great idea. Thanks!

    Thanks, Andrey, for making it a sticky! [​IMG]

  21. Cachette
    Brilliant_Rock

    Messages:
    1,629
    Joined:
    Dec 6, 2006
    by Cachette » Jan 31, 2008
    Thank you for the tips! I applied your tutorial just yesterday and got amazing results! (see Fire thread)

    Cachette [​IMG]

  22. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
    by strmrdr » Jan 31, 2008
    Your welcome!
    kewl pictures!!
    That makes the time spent on this project so very worth it!! :}
    Thanks!

  23. gtn
    Brilliant_Rock

    Messages:
    748
    Joined:
    Oct 24, 2007
    by gtn » Feb 14, 2008
    thanks for the tips. Time to try to take more pictures :)

  24. strmrdr
    Super_Ideal_Rock

    Messages:
    23,295
    Joined:
    Nov 1, 2003
  25. Diamond*Dana
    Ideal_Rock

    Messages:
    7,052
    Joined:
    Jul 21, 2006
    by Diamond*Dana » Feb 23, 2008
    Very informative, thank you strmrdr & wifey2b!

  26. wifey2b
    Brilliant_Rock

    Messages:
    772
    Joined:
    Aug 3, 2006
    by wifey2b » Feb 24, 2008
    Thank you all for the nice compliments, but I do have to admit - most of all this is Strms work. Most of the pics and all the write ups are his time and effort -
    I just want to thank everyone who appreciates my honey as much as I do...I am so terribly proud of him :}:}:} I am so blessed, and can''t wait to be wifey4fr rather than wifey2b.
    I know I don''t appear so much lately - but working and cold/flu has been keeping me away more, but will try to be here more often from now on :}
    HUGS you all are the greatest - well next to Strmy giggle :}[​IMG]

  27. CJ2008
    Ideal_Rock

    Messages:
    4,292
    Joined:
    Dec 31, 2006
    by CJ2008 » Apr 13, 2008
    this was so nice of both of you to do! I had the hardest time taking pictures of my ring! I''m going to try again, with these tips in mind! THANKS!
